1.Adopts advanced microcomputer control system, stable performance, the conveyor automatically send embryo;
2, Use infrared heating lamps, penetrating power strong, embryo heated while rotation, orbital revolution, heating uniformity, rapid and reliable;
3, Light tube in heating area, reflector width and height can be adjusted to suit the different structure preform heating, and automatic exhaust temperature device in order to ensure constant temperature of the drying tunnel;
4, Each machine has a safety self-locking device, when a processes have problem, the program will automatically switch to a safe state;
5, All the action drive by the cylinder, do not use pumps, with no pollution, low noise;
6, Gas way design divide action and air blowing into three parts, action to meet the needs of the different pressure of the blowing, action;
7, Cooling system to achieve the desired cooling effect; H- the bottle scrap rate less than 0.2 percent . 8, Pneumatic mould clamping made more stable operation; Blowing from bottom to top give higher correctness.
Model | Unit | AOK-2000 | |
| （Number of cavity） | cavities | 2 |
（clamping unit） | KG | 20000 | |
（mold stroke） | mm | 220 | |
（stretch stroke） | mm | 340 | |
(Bottom stroke) | mm | 50 | |
(Cavity pitch) | mm | 154.2 | |
(heating pitch) | mm | 190.5 | |
(Number of holder) | PCS | 66 | |
(Max.container volume | ltr | 5 | |
| Container | (Max. neck diameter) | mm | 150 |
(Max.prefrom height) | mm | 150 | |
(Max.container diameter) | mm | 175 | |
(Max.container height) | mm | 340 | |
(theoretical output) | B.P.H | 1000-1200 | |
| (heating oven) | UNITS | 412 |
(boxchannel) | Floor | 4 | |
(Number of lamp) | pcs | 48 | |
(heating power) | KW | 48 | |
(installed power) | KW | 52 | |
(voltage) | Voltage | 220v/380V/3phase | |
| Air System | （operating pressure） | kg/cm2 | 7 |
（blowing pressure） | mpa | 3.0-4.0 | |
（high pressure air consuming） | L/min | 3200 | |
（power） | KW | 18 | |
| Chiller System |
(temperature) | degree | 10-15 |
(pressure) | Mpa | 0.3-0.5 | |
(flow rate) | L/min | 40 | |
(heating power) | HP | 5 | |
| Machine | (machine dimension) | M | 3.82.02.2 |
(machine weight) | KG | 4000 | |
